Robot LOM/MRL series-Robot cladding LOM/MRL series-Leishi Intelligent Manufacturing Co., Ltd

MR Series

MR1835Robot LOM/MRL series

Highly integrated, circulating deoxygenation

Product Overview

The MRL series is a mobile robotic device designed for on-site repair of large equipment, especially for components that cannot be disassembled or transported. This equipment solves the challenge of rapid emergency repair for large machinery, eliminating the need for disassembly, transportation, off-site repair, and reinstallation. It significantly reduces labor intensity and repair time for workers, saving users a substantial amount of time and costs.

Learn More

Directional energy deposition technology

Laser is used to spray metal powder onto the surface of the workpiece, while forming a melting pool between the powder and the workpiece surface. Material deposition and forming are achieved by controlling the powder and energy input.

Sealed environmental box combined with circulating deoxygenation system

The oxygen content is controlled at ≤ 50ppm to meet the integrated printing requirements of various active metals such as titanium alloys, aluminum alloys, high-temperature alloys, and various steels. Circulating gas washing can control the internal oxygen and water content below 50ppm.

5-axis simultaneous control

Support rapid and precise molding of large and complex components, such as rocket engine parts, enabling direct printing of complex internal flow channels and lightweight structures, significantly optimizing the performance and production efficiency of aerospace components.

Carrier type powder feeder

Supports configuring 2-6 powder feeders, paired with powder buckets, to achieve continuous powder feeding without stopping, real-time powder mixing, and multifunctional gradient material powder feeding.

Larger space, highly integrated

The processing space is up to 1000 * 800 * 900mm; the structure is compact, all functions are integrated into the control panel, and safety signals are interlocked.
